Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate

Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate

Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate
Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate

Large Image :  Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate Get Best Price

Product Details:

Place of Origin: China
Brand Name: JINZHU
Certification: CE
Model Number: JZ-P3001

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard Export package
Delivery Time: 5-10 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30 sets per month
Detailed Product Description
Name: Stainless Steel Sheet Buffing Machine Finishing: Mirror Finishing
Use For: Flat Sheet Or Plate
High Light:

buffing machine for stainless steel

,

buffing and polishing machine

Stainless steel sheet polishing machine





Product Description

Stainless steel sheet buffing machine is specially designed for buffing various size of sheet or plate to get right finishing . In addition, the working table width of this machine is 600 mm and the length can be up to 6000 mm. The features of  sheet polishing machine are as below:

  • the size of working table can be customized (according to your items and requirement)
  • continuously working time almost 10 years and safety operation
  • less Maintenance rate than common machine
  • less deformation rate after polishing (almost less than 2%)
  • most noteworthy point is no vibration when working.

Specification

Stainless steel sheet buffing machine
Model JZ-P3001
Main motor 11 kw( the motor brand as your request)
Swing motor 0.37
Voltage 380 V, 50 HZ/60 HZ, 3 phase
Spindle speed 2300 r/min
polishing wheel flap wheel, abrasive wheel, cloth polishing wheel
polishing wheel size OD 250 mm*32mm and 300 mm *ID 32 mm
Mechanical operation PLC control ( For some irregular shape, we can use CNC control system)
Working condition dry condition
Remark with dust cover, no dust removing machine



Details section of Sheet buffing machine



Stainless Steel Sheet Metal Buffing Machine With Less Deformation Rate 0



Consumables usage

How to use consumables to get needed finish by this sheet polishing machine?

First of all, we can give you options at every point of polishing process by 3 levels buffing range and the range from 2B finishing to 100% 8K mirror finishing. also, you should know how to use right consumables and buffing process to achieve a profitable cost and get right polished finishing as you need.

  • with flap wheel to sweep the scratch line and sand-holes on the surface of the work piece
  • with sisal/hemp wheel to get Matt finishing of the metal sheet surface
  • with hard/soft cloth wheel to get mirror finishing
  • usually sisal/hemp wheel matches purple polishing wax; hard cloth wheel matches green buffing wax; soft cloth wheel matches white buffing wax

consumables usage for auto vacuum silver buffing machine

Finally for More information, Please contact directly
