Product Details:
Payment & Shipping Terms:
|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Condition: | Flexible,smart,practical.stable |
|---|---|---|---|
| Using: | Aluminum /iron /copper /SS/steel Plate Spinning Processing | Processing Diameter: | Customized 0-250mm |
| Warranty Period: | One Year | Machanical Operation: | Cnc |
| Use For: | Lamp Cover Spinning | Input: | Touch Screen |
| Quality: | 100% Quality Assurance | Warranty: | One Year Warranty |
| High Light: | cnc buffing machine,cnc metal spinning machine |
||
Dongguan Jinzhu Machinery Equipment Co., Ltd.
We are manufacturer of polishing machine and polishing consumables ,CNC metal spinning machine grinding machine ,sandblasting buffing machine for metal surface processing .such as stainless steel round/rectangular tube/pipe ,stainless steel sheet ,die-casting part .pots and pans, taps and handles, watch band, steel rings round steel lids and so on.
CNC aluminum led lampshade/ reflector making machine
Use for: aluminum /iron /copper /SS/steel plate spinning processing
applied to lighting,cooker,art and craft,mainly on mass production of barrel-shape,cone type,parabolic,horn type,projectile type produc such as LED aluminum cup,reflector,reflex cover and so on.
1. this machine designed for small and meidum diameter (30-300mm)plate spinning processing
2. high efficiency ,cycle time: 10 seconds
3. easy to operate, one skilled worker can operate more than one machine
4. special technique to make processing stable
Main Parameter
| Items | Parameter | ||
| processing capbility | Blanks | Diameter | 30-300 mm |
| Iron | Thickness | 0.5-1.0 mm | |
| Aluminum,Copper | 0.5-2.0 mm | ||
| Stainless Steel | 0.5-0.6 mm | ||
| Barrel diameter | 150 mm | ||
| Spindle center high | 150 mm | ||
| Two-center distance | 350 mm | ||
| Mian motor power | 3.7servo/frequency | ||
| Hydraulic Station Power | 1.5 kw | ||
| Spindle speed | 10-4000 rpm | ||
| Travel | landscape(X) | dia 400 mm | |
| portrait (Y) | 380 mm | ||
| Max.force | 10 kn | ||
| Travelanti-push device trip | 300 mm (can be customized to 800mm) | ||
| Positioning accuracy | 0.01 mm | ||
| Tool number(customized) | 2+2 sets | ||
1. by plywood case without fumigation
2. In 25-35 days after get the deposit
1. We will provide warranty for main spares and electric parts which have quality problems of the machine for 12 months from the date of shipment.
2. We will provide all technological guidance forever from the date of deposit by phone /email/video.
3. We guarantee that your worker can use the machine very well after our training.
How to get the right machine for your products?
If you want to get more information please feel free to contact me.
Best regards.
